ACF wound filter cartridge is made of high-efficiency active adsorption ACF material, which has good adsorption capacity for residual chlorine, heavy metals, odors, pigments, etc. The outer layer of the center rod is coated with a microfiber PP film to ensure the filter It will not leak carbon, and the skeleton interface is made of polypropylene material, which is made by hot melt welding without any adhesive or medium. It can replace the decolorization function of powder activated carbon production process.
Large specific surface area, high effective adsorption
Absorption and desorption strokes are short and fast
Excellent adsorption capacity
Easy to use; good strength, no secondary pollution
Water pollution purification treatment, removal of residual chlorine, deodorization, decolorization and filtration,
Various acid and alkaline solutions, washed and filtered.
Organic solvent filtration
It can replace the decolorization function of powder activated carbon production process. Juice drinks are decolorized and filtered. Decolorization and filtering of grease materials.
Filter Media | ACF, Options: PP,GF |
Support diversion layer | PP |
Extended/Center core | PP/GF |
Interface lining | No or stainless steel |
O-ring material | Silicone,Viton,EPDM,Buna-N |
Maximum working temperature | 80℃ (△P≤0.10Mpa) |
Maximum working pressure | Forward 4.2bar；Reverse1.5bar （25℃） |
PH range | 1-14 |
Cleanliness | The product itself does not have any foreign matter such as particles, fibers, etc. |
Biosafety | All ingredients meet USP (United States Pharmacopeia) Class VI plastic testing |
